executable source code blocks with org-babel






org-babel is the mechanism that org-mode offers for evaluating (executing)
blocks of source code embedded in your org-mode-documents. This is useful
for so-called reproducible research, i.e., where you allow your readers to go
through the steps that led to your results.



Here, I'm just scratching the surface with some simple examples.






source code blocks






Let's first look at how it all began: source code blocks. I guess most
org-mode-users will be familiar with those: the ability to include
syntax-highlighted ('font-locked') snippets of source code in
org-documents. We discussed source blocks before, they look like this:





#+begin_src perl
sub my_func {
print "Hello, world!\n";
}
#+end_src





And note that code blocks can be edited in their 'native mode' using C-c'= (or, =org-edit-src-code).



When code block like this are exported to, say, HTML, they'll look like the
following fully highlighted snippet (assuming you're reading Emacs-fu in
it's full-color version):





sub my_func {
print "Hello, world!\n";
}









evaluating source code






org-babel takes this a few steps further: instead of just looking at
source code, we can actually evaluate (execute) it, using the
org-mode-based system called org-babel.



If you have a recent version of org-mode (7.x or later), add the
following to your .emacs (or equivalent):





(org-babel-do-load-languages
'org-babel-load-languages
'( (perl . t)
(ruby . t)
(sh . t)
(python . t)
(emacs-lisp . t)
))





This enables org-babel for the mentioned languages; there are many
other languages available as well.



Now, suppose we have a snippet of python in an org-mode-buffer:





#+begin_src python
def hello(str):
return "Hello, " + str + "!"
return hello ("dude")
#+end_src





You can move the cursor (point) inside the src-block and press C-c C-c (or,
org-confirm-babel-evaluate). This causes the block of code to be evaluated
(executed), after asking you for confirmation. The result will inserted below
the block, like:





#+results:
: Hello, dude!





Note, in the hello example, the result of the block is the value of the
evaluation - that is, the value of the last expression evaluated. This is
the also the default, so we don't need to (but could) write:





#+begin_src python :results value





The alternative is to use the (standard) output of the function, which is
activated with :results output, e.g.:





#+begin_src sh :results output
echo "Hello $USER! Today is `date`"
#+end_src





Moving to this block and pressing C-c C=c would get you something like
the following – probably with a different username and time:





˜#+results:
: Hello djcb! Today is Sun Feb 27 13:51:50 EET 2011









almost like functions






org-babel also allows you to refer to the code blocks from elsewhere in
your document, by labeling your code-blocks with srcname. Let's say we
have some Ruby code to revert a string:





#+begin_src ruby
def revert(s)
if s == "" then
return ""
else
return s[-1].chr + revert(s.slice(0, s.length()-1))
end
end
revert(str)
#+end_src





We can now 'call' this block; note that we get the result of evaluating the block. So if you want to use the result of a function in the block, you also
need to add the call to that function (see the last line).



Now, we can use:





#+call: revert(str="VeryCoolStuff")





And we get:





: ffutSlooCyreV





Note, due to some limitation/bug in my version of org-babel, the strings
should not contain spaces or other special characters, so the following
will give result in an error note:





˜#+call: revert(str="Very Cool Stuff")





Whenever you try to evaluate a code block, emacs will ask for confirmation --
this is important, because of the obvious security implications of executing
unknown code. Anyway, if you do trust the code, you can use the following
to skip the confirmation:





(setq org-confirm-babel-evaluate nil)





These simple examples do not really capture the power that org-babel
brings, but it's a start. There is quite a bit of documentation for
org-babel to help you further. Finally, if you are already using
org-babel, feel free to share your experiences in the comments!



keeping your secrets secret






If you want to keep your secrets secret, it is a good idea to encrypt your
data; I usually do that for files with passwords for various services, banking
data, and so on. Since version 23, Emacs includes a package called EasyPG (an
interface to GnuPG) which makes this seamless – just make sure that you have
GnuPG installed.



It's easy to use EasyPG – the only thing you need to do is adding the .gpg
-extension to your files, and EasyPG will automatically encrypt/decrypt them
when writing/reading. So, for example, to create an encrypted org-mode-file,
simply visit (C-x C-f) a file with a name like myfile.org.gpg; emacs opens
this in Org-Mode (just like any .org-file). When you want to save the file,
emacs will ask you for a password, and with this same password, you can open
it again. Don't forget that password!







account data






You can store any kind of secret data in your encrypted files. One type I
find particularly useful is to store account data (user names, passwords)
for various services there. For example, I use the emacs identi.ca-mode client, which gets its account data through variables identica-username and
identica-password.



I do not want to put this information in my main .emacs file for safety
reasons, but instead, put it an encrypted file, together with the account data
for other services (mail, twitter etc.). Emacs' require does not understand
encrypted files, but load-library does. To deal with that, I have two files,
secrets.el and secrets.el.gpg (in my load-path):





;; secrets.el
(load-library "secrets.el.gpg")
(provide 'secrets)





and





;; secrets.el.gpg
(setq identica-username "djcb"
identica-password "$ekr3t")
;; ... other passwords ...





Now, in my .emacs I have a function for various services, like:





(defun start-identica ()
(interactive)
(require 'secrets)
(identica-friends-timeline))





This will prompt me for the password, but only if I use anything that requires
the secret data, and only once per session.




Update: as Richard notes in the comments, you can also use require by
explicitly specifying the filename (parameter two). That might actually be easier --
thanks Richard!








using public keys






By default, EasyPG performs symmetric encryption; if you want to use public key encryption instead (useful when you want to share the encrypted files with
others), you can use:





;; 'silent to use symmetric encryption
;; nil to ask for users unless specified
;; t to always ask for a user
(setq epa-file-select-keys t)





The 'users' in this snippet are the people in your GnuPG-keyring – EasyPG
lists your keyring inhabitants, allowing for easy selection. You can also
specify the people who can decrypt your file by putting something like the
following at the beginning of the file you want to encrypt.





# -*- epa-file-encrypt-to: ("foo@bar.org") -*-









so






EasyPG brings more functionality for encryption, decryption, signing, managing
your keyring and so on, but I haven't used that much yet. Anyhow, the
automatic support for reading/writing file is really nice.




booorriiiing!!!!!!!!!!!!!!!!!!!!!








it's 7 a.m.....i woke up early just to snap this pic..lol
well, today I got so bored and I'm doing some crazy stuff again..well, I just snapped some view from my balcony..well, I lived in 12th floor and I'm kinda scared when looking at the ground from above.. whew.. It'll be surely a miracle if I don't die when I jumped from the 12th floor isn't it.....?gosh..what am I thinking..well, yeah this is just some pic of it..

extending ERC with your own commands






ERC is the leading Emacs-based IRC-client; I already discussed ERC before. I
have been using ERC a lot in recent times, as it's an essential way to
communicate at work with team members in remote locations. There are other
IRC-clients – most people around me seem to use either irssi or xchat,
but these don't integrate so well with my emacs-based workflow, the easy with
which it can be extended to do exactly what I want; in this although they have
their own strenghts. One of the great strengths of ERC is article I give some
examples.



Apart from chatting, you can send commands (long list) to the IRC-server,
for example to request information about other users, change your 'nick',
leave the channel, and so on. As in most IRC-clients, you can send these
commands with ERC by prefixing them with /, so you'd type:





/nick ninjaturtle





to change your nickname.



The nice thing about ERC is how easy it to add your own commands to this. In
your .emacs (after loading ERC), you can add something like:





(defun erc-cmd-MYSYSTEM ()
"show some information about my system"
(let ((str (shell-command-to-string "uname -a")))
(when str (erc-send-message str))))





Or, add add a function called erc-cmd-XXXX (with the XXXX being the
command name in capitals, will add command XXXX, which you can invoke with
/XXXX or /xxxx). So, with the above function, I can now do something like:





ERC> /mysystem
<djcb> Linux cthulhu 2.6.35-25-generic #44 SMP Fri Jan 21 17:40:48 UTC
2011 i686 GNU/Linux





Let's look at some other (somewhat) useful command: /calc; again, just a
small example, I'm sure something can come up with something a bit more
elegant - perhaps using emacs' built-in calc.





(defun erc-cmd-CALC (&rest args)
"calculate value of some expression using bc"
(let ((expr (mapconcat 'identity args " ")))
(when (length expr)
(let ((result (shell-command-to-string (concat "echo '" expr "' | bc "))))
(when result (erc-send-message (concat expr " = " result)))))))







ERC> /calc 2 * (3 + 4) / 7
<djcb> 2 * (3 + 4) / 7 = 2





Now, a small warning, just because it's easy to dump the output of, say,
cowsay in an IRC-channel using your own /cowsay command, does not mean it is
a good idea – in fact, using something like that is guaranteed to get you
kicked out fairly quickly from many channels.



That being said, I'm sure many people have come up with much more clever
things than the examples here; feel free to share your inventions in the
comments!
